Product Features
High speed CPU digital intelligent control, auto-adjusting optimum output ; Excellent follow performance of arc, high-speed reaction rate; Built-in software control system with human imitating thinking, automatically match the welding parameters in different conditions according to material, solder wire, gas, and function; Super wide power grid voltage design, complete protection function, the preparation function of digital display parameter;
The welding heat input does not change with the power network voltage, constant heat input of arc welding; Environmental protection, energy saving, small in size, light in weight; Upgradeable welding software in different metallic materials.
Technical Parameters
Parameters | SZZN-PSA500 | Remarks | Rated power supply voltage (V) | 380 |
1. Available for all kinds of acid and alkaline welding rod, and cellulose-based electrode vertical down welding. 2. Suitable for welding all kinds of low, medium and high carbon steel, low alloy steel and stainless steel.
| Rated input current (A) | 36 | Input voltage range (V) | 110-465 | Rated welding voltage (V) | 18-40 | | Output no-load voltage (V) | 75 | Duty cycle (%) | 85 | Efficiency (%) | 95 | Power factor | 0.95 | Weight (kg) | 13
| Overall dimensions (mm) | 490*240*240 |
|
